TEK 7A26 : Amplifier Plug-In ; DC to 200MHz ; 5 mV/div to 5 V/div
TEK 7A29
TEK 7B15
TEK 7B53A
TEK 7B80 : Delayed Time Base Plug-In ; 1 ns to 5 s/div ; Triggering to
400MHz
TEK 7B85
TEK 7B87
TEK 7B92A : Dual Time Base Plug-In ; 0.5 ns/div to 0.2 s/div ;
Triggering to 500MHz
TEK 7L12
TEK 7D12
TEK 7D15
TEK7L12 頻譜儀插件
中心頻率范圍 100 kHz to 1800 MHz
Resolution bandwidth : 300 Hz to 3 MHz
frequency steps are in 1-2-5 sequence from 500/div to 100 MHz/div
Automatic phase lock results in good stability.
with -115 dBm sensitivity at 300 Hz
70 dB spurious-free display dynamic range
Display modes : Log 10 Db/div, Log 2Db/div, Lin.
Reference level is from -100 dBm to +30 dBm
This unit has SMA connectors for a tracking generator connection to the LO1
and LO2 oscillators and the newer LED readout of the reference level. This TEK
analyzer unit has an advantage over the wider 7l13 units as it takes up only 2
slots in your scope rather than 3 with the 7L13 leaving some room for additional
plugins and the SMA LO connections allow connection of a variety of tracking
generators. This unit is complete with all knobs and controls . The 7l12
analyzer displays frequencies from 100kHz to 1.8 GHz and but does not have
digital storage like the 7L5, 7L14 and 7L18 featured.
