·100MHz帶寬，5GS/s的重復采樣率，實時采樣率25MS/s,30K超深內存
·按一個按鍵就可獲得40我種測量功能
·帶時間標記的趨勢繪圖迅速解決間歇故障造成的問題
·堅固耐用。密封、防水、防塵、防污染
·充電一次可使用四小時
·30K超深內存，示波記錄功能準確記錄長屏幕的波形
·外部觸發，書刊號排除復雜的故障
·帶行計數器的視頻觸發功能
·直接與PC或打印查相連
| Bandwidth | 100 MHz | |
| Number of Channels | 2 | |
| Max. Repetitive Sample Rate | 5GS/s | |
| Scope Record | 30k | |
| Continuous Autoset | Yes | |
| Measure Menu Automatic Setups | Yes | |
| Multimeter Display with Full Width Waveform | Yes | |
| Time/Division | 5ns-60s | |
| Vertical Resolution & Max. Sensitivity | 8 bits, 1mV/div | |
| Video Triggering & Pre/Post Trigger | Yes | |
| Envelope & Variable Persistance Display | Yes | |
| Oscilloscope Cursor Reading | Yes | |
| Glitch Capture | 40ns | |
| Automatic Setup Measurements | 40 | |
| Screen Memory | 10 | |
| Waveform Memory | 20 | |
| Set-up Memory | 40 | |
| Waveform Math & Filter | Yes | |
| Signal Generator Output - 4 Fixed Frequencies | Yes | |
| Component Tester Output - Volts & Current | Yes | |
| Optically Isolated RS-232 Interface for Printer & PC | Yes | |
| PC Software(Windows) & Cable | Optional | |
| CRT 4.7" diag./Backlit Display | Yes | |
| DC Volt | 300mV - 300V | |
| AC Volt True RMS | 300mV - 250V | |
| Resistance | 30 - 30MΩ | |
| Frequency | 1Hz - 5MHz | |
| dBm | 16 settings | |
| dBW/Audio Watts | 1,2,4,8,50W | |
| TrendPlot with Time & Date Stamp | Yes | |
